Quantech QTC4 STYLE A Series User Manual

SECTION 5 - TECHNICAL DATA
QUANTECH
73
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
5
TABLE 9 - OPTIONAL THREE-PASS REAR INLET/FRONT OUTLET EVAPORATOR (CONT'D)
ALL DIMENSIONS - INCHES (MM)
QTC4
A B C D
E
NOZZLE
SIZE
WATER
VOLUME
GALLONS
(LITERS)
MINIMUM
CHILLED
WATER FLOW
RATE
GPM (L/S)
MAXIMUM
CHILLED
WATER
FLOW RATE
GPM (L/S)
MODEL
COND.
230 S
14.1
(358)
25.5
(648)
73.2
(1859)
56.1
(1425)
5
58
(220)
170 (11) 650 (41)
240 H
15.3
(389)
26.7
(678)
29.9
(759)
56.1
(1425)
6
71
(269)
200 (13) 780 (49)
240 P
15.3
(389)
26.7
(678)
122.9
(3122)
70
(1778)
6
71
(269)
200 (13) 780 (49)
260 S
15.3
(389)
26.7
(678)
117.1
(2974)
56.1
(1425)
5
58
(220)
170 (11) 650 (41)
270 C
15.3
(388)
26.7
(678)
16.8
(427)
51.9
(1318)
6
82
(310)
200 (13) 780 (49)
270 S
15.3
(389)
26.7
(678)
42.9
(1090)
70
(1778)
6
82
(310)
200 (13) 780 (49)
270 H
15.5
(394)
29.5
(749)
88.6
(2250)
71.8
(1824)
6
113
(428)
270 (17) 1060 (67)
270
P
15.5
(394)
29.5
(749)
88.3
(2243)
71.8
(1824)
6
113
(428)
270 (17) 1060 (67)
290 H
15.5
(394)
29.5
(749)
88.6
(2250)
71.8
(1824)
6
113
(428)
270 (17) 1060 (67)
300 S
15.3
(389)
26.7
(678)
122.9
(3122)
70
(1778)
6
71
(269)
200 (13) 780 (49)
NOTE: Minimum Chilled Water Flow Rate is for full load selections; Variable Primary Flow ratings as low as 50% of the minimum are permitted.
Glycol limits are higher. Please contact your Quantech Sales Representative for ratings and further information.
