QUANTECH
74
SECTION 5 - TECHNICAL DATA
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
ALL DIMENSIONS - INCHES (MM)
QTC4
A B C D
E
NOZZLE
SIZE
WATER
VOLUME
GALLONS
(LITERS)
MINIMUM
CHILLED
WATER FLOW
RATE
GPM (L/S)
MAXIMUM
CHILLED
WATER
FLOW RATE
GPM (L/S)
MODEL
COND.
300 H
15.3
(389)
26.7
(678)
166.9
(4239)
70
(1778)
6
71
(269)
200 (13) 780 (49)
310 P
15
(381)
30.3
(770)
132.2
(3358)
71.8
(1824)
6
113
(428)
270 (17) 1060 (67)
315 P
15
(381)
29.5
(749)
176.6
(4486)
71.8
(1824)
6
113
(428)
270 (17) 1060 (67)
320 S
15.5
(394)
29.5
(749)
88.6
(2250)
71.8
(1824)
6
113
(428)
270 (17) 1060 (67)
330 S
15.3
(389)
26.7
(678)
166.9
(4239)
70
(1778)
6
71
(269)
200 (13) 780 (49)
340 S
15.5
(394)
29.5
(749)
132.6
(3368)
71.8
(1824)
6
113
(428)
270 (17) 1060 (67)
340 H
15.5
(394)
29.5
(749)
176.2
(4475)
71.8
(1824)
6
113
(428)
270 (17) 1060 (67)
370 P
16.3
(414)
30.3
(770)
208.6
(5298)
83.5
(2121)
8
147
(556)
370 (23) 1440 (91)
370 S
15.8
(401)
28.8
(732)
180.9
(4595)
112.2
(2850)
6
94
(356)
280 (18) 1100 (69)
370 H
16.3
(414)
30.3
(770)
164.3
(4173)
83.4
(2118)
8
147
(556)
370 (23) 1440 (91)
TABLE 9 - OPTIONAL THREE-PASS REAR INLET/FRONT OUTLET EVAPORATOR (CONT'D)
NOTE: Minimum Chilled Water Flow Rate is for full load selections; Variable Primary Flow ratings as low as 50% of the minimum are permitted.
Glycol limits are higher. Please contact your Quantech Sales Representative for ratings and further information.
