Quantech QTC4 STYLE A Series User Manual

QUANTECH
158
SECTION 9 - MAINTENANCE
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
TABLE 28 - PRESSURE TRANSDUCER OUTPUT VOLTAGE (MEASURED SIGNAL TO RETURN AT THE
TRANSDUCER)
SUCTION PRESSURE TRANSDUCER
(125 PSIG)
DISCHARGE CONDENSER LIQUID PRESSURE AND
DISCHARGE PRESSURE TRANSDUCER
(400 PSIG)
PRESSURE VOLTAGE PRESSURE VOLTAGE
0 0.50 0 0.50
5 0.66 25 0.75
10 0.82 50 1.00
15 0.98 75 1.25
20 1.14 100 1.50
25 1.30 125 1.75
30 1.46 150 2.00
35 1.62 175 2.25
40 1.78 200 2.50
45 1.94 225 2.75
50 2.10 250 3.00
55 2.26 275 3.25
60 2.42 300 3.50
65 2.58 325 3.75
70 2.74 350 4.00
75 2.90 375 4.25
80 3.06 400 4.50
85 3.22
90 3.38
95 3.54
100 3.70
105 3.86
110 4.02
115 4.18
120 4.34
125 4.50
