Quantech QTC4 STYLE A Series User Manual

SECTION 5 - TECHNICAL DATA
QUANTECH
71
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
5
ALL DIMENSIONS - INCHES (MM)
QTC4
A B C D
E
NOZZLE
SIZE
F G
WATER
VOLUME
GALLONS
(LITERS)
MINIMUM
CHILLED
WATER
FLOW RATE
GPM (L/S)
MAXIMUM
CHILLED
WATER
FLOW RATE
GPM (L/S)
MODEL
COND.
400 P
16.3
(414)
14
(356)
252.5
(6414)
– 8
83.5
(2121)
–
147
(556)
550 (35) 2160 (136)
405 S
15.5
(394)
14
(356)
164.6
(4181)
– 8
83.8
(2129)
–
130
(492)
470 (30) 1870 (118)
410 H
15.5
(394)
14
(356)
252.6
(6416)
– 8
83.8
(2129)
–
130
(492)
470 (30) 1870 (118)
410 P
16.3
(414)
14
(356)
296.5
(7531)
– 8
83.5
(2121)
–
147
(556)
550 (35) 2160 (136)
450 S
15.8
(401)
13
(330)
287.1
(7292)
282.5
(7177)
8
94.2
(2393)
89.7
(2278)
96
(363)
420 (26) 1660 (105)
490 H
16.3
(414)
14
(356)
308.4
(7833)
– 8
71.5
(1816)
–
147
(556)
550 (35) 2160 (136)
460 S
15.8
(401)
13
(330)
331.2
(8412)
326.6
(8296)
8
94.2
(2393)
89.7
(2278)
96
(363)
420 (26) 1660 (105)
470 C
15.5
(394)
14
(355)
176.5
(4482)
– 8
71.7
(1820)
–
130
(492)
470 (30) 1870 (118)
480 C
16.3
(414)
14
(356)
176.2
(4475)
– 8
71.5
(1816)
–
147
(556)
550 (35) 2160 (136)
500 S
16.3
(414)
14
(356)
308.4
(7833)
– 8
71.5
(1816)
–
147
(556)
550 (35) 2160 (136)
TABLE 8 - STANDARD TWO-PASS, REAR INLET/OUTLET EVAPORATOR (CONT'D)
NOTE: Minimum Chilled Water Flow Rate is for full load selections; Variable Primary Flow ratings as low as 50% of the minimum are permitted.
Glycol limits are higher. Please contact your Quantech Sales Representative for ratings and further information.
