Quantech QTC4 STYLE A Series User Manual

QUANTECH
70
SECTION 5 - TECHNICAL DATA
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
ALL DIMENSIONS - INCHES (MM)
QTC4
A B C D
E
NOZZLE
SIZE
F G
WATER
VOLUME
GALLONS
(LITERS)
MINIMUM
CHILLED
WATER
FLOW RATE
GPM (L/S)
MAXIMUM
CHILLED
WATER
FLOW RATE
GPM (L/S)
MODEL
COND.
300 H
15.3
(389)
11.4
(290)
166.8
(4237)
– 6
70
(1778)
–
71
(269)
300 (19) 1170 (74)
310 P
15.5
(394)
14
(356)
132.2
(3358)
– 8
83.4
(2118)
–
113
(428)
410 (26) 1600 (101)
315 P
15.5
(394)
14
(356)
176.21
(4476)
– 8
83.4
(2118)
–
113
(428)
410 (26) 1600 (101)
320 S
15.5
(394)
14
(356)
88.6
(2250)
– 8
83.4
(2118)
–
113
(428)
410 (26) 1600 (101)
330 S
15.3
(389)
11.4
(290)
166.9
(4239)
– 6
83.4
(2118)
–
71
(269)
300 (19) 1170 (74)
340 S
15.5
(394)
14
(356)
132.2
(3358)
– 8
83.4
(2118)
–
113
(428)
410 (26) 1600 (101)
340 H
15.5
(394)
14
(356)
176.2
(4475)
– 8
83.4
(2118)
–
113
(428)
410 (26) 1600 (101)
370 P
16.3
(414)
14
(356)
208.5
(5296)
– 8
83.4
(2118)
–
147
(556)
550 (35) 2160 (136)
370 S
15.8
(401)
13
(330)
180.9
(4595)
176.4
(4480)
8
112.2
(2850)
107.7
(2735)
96
(363)
420 (26) 1660 (105)
370 H
16.3
(414)
14
(356)
164.4
(4176)
– 8
83.4
(2118)
–
147
(556)
550 (35) 2160 (136)
TABLE 8 - STANDARD TWO-PASS, REAR INLET/OUTLET EVAPORATOR (CONT'D)
NOTE: Minimum Chilled Water Flow Rate is for full load selections; Variable Primary Flow ratings as low as 50% of the minimum are permitted.
Glycol limits are higher. Please contact your Quantech Sales Representative for ratings and further information.
