SECTION 5 - TECHNICAL DATA
QUANTECH
69
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
5
ALL DIMENSIONS - INCHES (MM)
QTC4
A B C D
E
NOZZLE
SIZE
F G
WATER
VOLUME
GALLONS
(LITERS)
MINIMUM
CHILLED
WATER
FLOW RATE
GPM (L/S)
MAXIMUM
CHILLED
WATER
FLOW RATE
GPM (L/S)
MODEL
COND.
230 S
15.1
(384)
11.4
(290)
73.3
(1862)
– 6
56.1
(1425)
–
58
(220)
250 (16) 980 (62)
240 H
15.3
(389)
11.4
(290)
29.9
(759)
– 6
56.1
(1425)
–
71
(269)
300 (19) 1170 (74)
240 P
15.3
(389)
11.4
(290)
122.9
(3122)
– 6
70
(1778)
–
71
(269)
300 (19) 1170 (74)
260 S
15.3
(389)
11.4
(290)
117.3
(2979)
– 6
56.1
(1425)
–
58
(220)
250 (16) 980 (62)
270 C
15.3
(388)
11.4
(290)
16.8
(427)
– 6
51.9
(1318)
–
82
(310)
300 (19) 1170 (74)
270 S
15.3
(389)
11.4
(290)
42.9
(1090)
– 6
70
(1778)
–
82
(310)
300 (19) 1170 (74)
270 H
15.5
(394)
14
(356)
44.3
(1125)
– 8
71.8
(1824)
–
113
(428)
410 (26) 1600 (101)
270 P
15
(381)
14
(356)
88.3
(2243)
– 8
71.8
(1824)
–
113
(428)
410 (26) 1600 (101)
290 H
15.5
(394)
14
(356)
88.3
(2243)
– 8
71.8
(1824)
–
113
(428)
410 (26) 1600 (101)
300 S
15.3
(389)
11.4
(290)
122.9
(3122)
– 6
70
(1778)
–
71
(269)
300 (19) 1170 (74)
TABLE 8 - STANDARD TWO-PASS, REAR INLET/OUTLET EVAPORATOR (CONT'D)
NOTE: Minimum Chilled Water Flow Rate is for full load selections; Variable Primary Flow ratings as low as 50% of the minimum are permitted.
Glycol limits are higher. Please contact your Quantech Sales Representative for ratings and further information.
