Quantech QTC4 STYLE A Series User Manual

SECTION 5 - TECHNICAL DATA
QUANTECH
65
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
5
TABLE 7 - OPTIONAL ONE-PASS EVAPORATOR (CONT'D)
ALL DIMENSIONS - INCHES (MM)
QTC4
A,B C D
E
NOZZLE
SIZE
WATER
VOLUME.
GALLONS
(LITERS)
MINIMUM
CHILLED
WATER FLOW
RATE
GPM (L/S)
MAXIMUM
CHILLED
WATER FLOW
RATE
GPM (L/S)
MODEL
COND.
230 S
20.8
(528)
73.2
(1859)
56.1
(1425)
8
58
(220)
500
(32)
1970
(124)
240 H
21
(533)
92.9
(2360)
56.1
(1425)
8
71
(269)
590
(37)
2190
(138)
240 P
21
(533)
122.9
(3122)
70
(1778)
8
71
(269)
590
(37)
2190
(138)
260 S
21
(533)
117.1
(2974)
56.1
(1425)
8
58
(220)
500
(32)
1970
(124)
270 C
21
(533)
16.8
(427)
51.9
(1318)
8
82
(310)
590
(37)
2190
(138)
270 S
21
(533)
42.9
(1090)
70
(1778)
8
82
(310)
590
(37)
2190
(138)
270 H
22.5
(572)
44.7
(1135)
71.8
(1824)
10
113
(428)
810
(51)
3200
(202)
270 P
22.5
(572)
88.3
(2243)
71.8
(1824)
10
113
(428)
810
(51)
3200
(202)
290 H
22.5
(572)
88.6
(2250)
71.8
(1824)
10
113
(428)
810
(51)
3200
(202)
300 S
21
(533)
122.9
(3122)
70
(1778)
8
71
(269)
590
(37)
2190
(138)
NOTE: Minimum Chilled Water Flow Rate is for full load selections; Variable Primary Flow ratings as low as 50% of the minimum are permitted.
Glycol limits are higher. Please contact your Quantech Sales Representative for ratings and further information.
