QUANTECH
52
SECTION 4 - INSTALLATION
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
FIELD WIRING LUGS
HIGH AIRFLOW/HIGH STATIC CONDENSER FANS
TERMINAL
BLOCK
CIRCUIT
BREAKER
NON-FUSED
DISCONNECT SWITCH
QTC4 MODEL
INPUT
VOLTS
INPUT
FREQ
WIRE
PER
PHASE
LUG
WIRE
RANGE
WIRES
PER
PHASE
LUG
WIRE
RANGE
WIRES
PER
PHASE
LUG
WIRE
RANGE
MODEL COND EVAP
SINGLE POINT WIRING
290 H E
200 60
230 60
380 60 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
400 50 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
460 60 3 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 3 #2 - 600 kcmil
575 60 3 #2 - 600 kcmil 3 #3/0 ~ 400 kcmil 3 #2 - 600 kcmil
300 S C
200 60
230 60
380 60 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
400 50 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
460 60 3 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 3 #2 - 600 kcmil
575 60 3 #2 - 600 kcmil 3 #3/0 ~ 400 kcmil 3 #2 - 600 kcmil
300 H C
200 60
230 60
380 60 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
400 50 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
460 60 3 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 3 #2 - 600 kcmil
575 60 3 #2 - 600 kcmil 3 #3/0 ~ 400 kcmil 3 #2 - 600 kcmil
310 P E
200 60
230 60
380 60 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
400 50 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
460 60 3 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 3 #2 - 600 kcmil
575 60 3 #2 - 600 kcmil 3 #3/0 ~ 400 kcmil 3 #2 - 600 kcmil
315 P E
200 60
230 60
380 60 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
400 50 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
460 60 3 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 3 #2 - 600 kcmil
575 60 3 #2 - 600 kcmil 3 #3/0 ~ 400 kcmil 3 #2 - 600 kcmil
320 S E
200 60
230 60
380 60 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
400 50 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
460 60 3 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 3 #2 - 600 kcmil
575 60 3 #2 - 600 kcmil 3 #3/0 ~ 400 kcmil 3 #2 - 600 kcmil
330 S C
200 60
230 60
380 60 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
400 50 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
460 60 3 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 3 #2 - 600 kcmil
575 60 3 #2 - 600 kcmil 3 #3/0 ~ 400 kcmil 3 #2 - 600 kcmil
340 S E
200 60
230 60
380 60 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
400 50 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
460 60 3 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 3 #2 - 600 kcmil
575 60 3 #2 - 600 kcmil 3 #3/0 ~ 400 kcmil 3 #2 - 600 kcmil
340 H E
200 60
230 60
380 60 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
400 50 4 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 4* #2 - 600 kcmil
460 60 3 #2 - 600 kcmil 4 #4/0 ~ 500 kcmil 3 #2 - 600 kcmil
575 60 3 #2 - 600 kcmil 3 #3/0 ~ 400 kcmil 3 #2 - 600 kcmil
TABLE 4 - ELECTRICAL LUG DATA (CONT'D)
