Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 68
Scale calibration codes are defined below.
Scrape Screen
This command causes the CubiScan 25 to save the current touchscreen image to the file
cs125isc.bmp.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Scale Calibration Alpha (S) 53h
3 6 Test Weight Value Numeric 010.00-025.00
91End of Text Control(ETX) 03h
10 1 Carriage Return Control (CR) 0Dh
11 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Scale Calibration Alpha (S) 53h
3 1 Acknowledge Alpha (A) 41h
4 2 Identifier Numeric (00-99)
61End of Text Control(ETX) 03h
7 1 Carriage Return Control (CR) 0Dh
81Line Feed Control(LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Scale Calibration Alpha (S) 53h
31Neg. Acknowledge Alpha (N) 4Eh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Scrape Command Alpha (a) 61h
31End of Text Control(ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
51Line Feed Control(LF) 0Ah
Acknowledge Format
