Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 72
Smallest Box Mode
This command causes the CubiScan 25 to calculate measurements based on the smallest box.
Test
This command causes the CubiScan 25 to reply with an error code. A response of TA00 means
that the CubiScan 25 is ready and responding to transmissions from the host. If the host receives
no response from the control unit after sending this command, an error condition exists in the
communications between the host and controller.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Smallest Box Command Alpha (j) 6Ah
31End of Text Control(ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
51Line Feed Control(LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Smallest Box Command Alpha (j) 6Ah
3 1 Acknowledge Alpha (A) 41h
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Smallest Box Command Alpha (j) 6Ah
31Neg. Acknowledge Alpha (N) 4Eh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Self Test Command Alpha (T) 54h
31End of Text Control(ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
