Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 73
Units
This command causes the CubiScan 25 to report its current unit settings, dimensional factor, and
location ID.
51Line Feed Control(LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Self Test Command Alpha (T) 54h
3 1 Acknowledge Alpha (A) 41h
4 2 Identifier Numeric (00-99)
61End of Text Control(ETX) 03h
7 1 Carriage Return Control (CR) 0Dh
81Line Feed Control(LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Self Test Command Alpha (T) 54h
31Neg. Acknowledge Alpha (N) 4Eh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Values Command Alpha (U) 55h
31End of Text Control(ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
51Line Feed Control(LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Units Command Alpha (U) 55h
3 1 Acknowledge Alpha (A) 41h
4 1 Dimension Units Alpha (E/M) 45h or 4Dh
5 1 Weight Units Alpha (E/M 45h or 4Dh
6 1 Factor Units Alpha (D/I) 44h or 49h
7 4 Dimensional Factor Numeric 0000-9999
Pos Len Description Type Range ASCII
