Quantronix CUBISCAN 25 User Manual

Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 74
Values
This command causes the CubiScan 25 to report various internal parameters. This is useful for
troubleshooting.
11 6 Location ID Alpha
000000-ZZZZZ
Z
17 1 End of Text Control (ETX) 03h
18 1 Carriage Return Control (CR) 0Dh
19 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Units Command Alpha (U) 55h
31Neg. Acknowledge Alpha (N) 4Eh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
21Values Command Alpha (V) 56h
3 1 End of Text Control (ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
5 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
21Values Command Alpha (V) 56h
3 1 Acknowledge Alpha (A) 41h
4 4 Length DBW Numeric 00.0-99.9
8 1 Comma Alpha (,) 2Ch
94Width DBW Numeric00.0-99.9
13 1 Comma Alpha (,) 2Ch
14 4 Height DBW Numeric 00.0-99.9
18 1 Comma Alpha (,) 2Ch
19 4 Length CPI Numeric 0000-9999
23 1 Comma Alpha (,) 2Ch
24 4 Width CPI Numeric 0000-9999
Pos Len Description Type Range ASCII
