Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 75
28 1 Comma Alpha (,) 2Ch
29 4 Height CPI Numeric 0000-9999
33 1 Comma Alpha (,) 2Ch
34 4 Length Blanking Numeric 0.00-9.99
38 1 Comma Alpha (,) 2Ch
39 4 Width Blanking Numeric 0.00-9.99
43 1 Comma Alpha (,) 2Ch
44 4 Height Blanking Numeric 0.00-9.99
48 1 Comma Alpha (,) 2Ch
49 4 Length Gain Numeric 00.0-99.9
53 1 Comma Alpha (,) 2Ch
54 4 Width Gain Numeric 00.0-99.9
58 1 Comma Alpha (,) 2Ch
59 4 Height Gain Numeric 00.0-99.9
63 1 Comma Alpha (,) 2Ch
64 2 Length Pulses Numeric 00-99
66 1 Comma Alpha (,) 2Ch
67 2 Width Pulses Numeric 00-99
69 1 Comma Alpha (,) 2Ch
70 2 Height Pulses Numeric 00-99
72 1 Comma Alpha (,) 2Ch
73 3 Length Wait Time Numeric 000-999
76 1 Comma Alpha (,) 2Ch
77 3 Width Wait Time Numeric 000-999
80 1 Comma Alpha (,) 2Ch
81 3 Height Wait Time Numeric 000-999
84 1 Comma Alpha (,) 2Ch
85 4 Model Number Alpha
“50” /
“100L”
89 1 Comma Alpha (,) 2Ch
90 3 Scale Capacity - English Numeric 000-999
50=10,20,30
100=100,150,2
01
93 1 Comma Alpha (,) 2Ch
94 5 Firmware Version Alpha 0.000-9.999
99 1 Future Growth Alpha Space 0h
100 2
Firmware Build
Number
Numeric 00-99
Pos Len Description Type Range ASCII
