Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 76
Values 2
This command causes the CubiScan 25 to report more of its various internal parameters. This is
useful for troubleshooting.
102 1 Comma Alpha (,) 2Ch
103 4 FPGA Build Number Numeric 0.00-9.99
107 1 Comma Alpha (,) 2Ch
108 8 Serial Number Numeric
00000000-
99999999
116 1 Comma Alpha (,) 2Ch
117 10 Future Growth Alpha Space 0h
127 1 End of Text Control (ETX) 03h
128 1 Carriage Return Control (CR) 0Dh
129 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
21Values Command Alpha (V) 56h
3 1 Neg. Acknowledge Alpha (N) 4Eh
4 1 End of Text Control (ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
6 1 Line Feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
21Values Command Alpha (v) 76h
3 1 End of Text Control (ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
5 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
21Values Command Alpha (v) 76h
3 1 Acknowledge Alpha (A) 41h
4 4 Length CPI Numeric 0000-9999
8 1 Comma Alpha (,) 2Ch
9 4 Width CPI Numeric 0000-9999
13 1 Comma Alpha (,) 2Ch
Pos Len Description Type Range ASCII
