Quantronix CUBISCAN 25 User Manual

Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 77
Weight Units
This command is used to set the weight units to either English (pounds) or metric (kilograms)
mode.
14 4 Height CPI Numeric 0000-9999
18 1 Comma Alpha (,) 2Ch
19 2 Length Pulses Numeric 00-99
21 1 Comma Alpha (,) 2Ch
23 2 Width Pulses Numeric 00-99
25 1 Comma Alpha (,) 2Ch
26 2 Height Pulses Numeric 00-99
28 1 Comma Alpha (,) 2Ch
29 2 Length Temperature Numeric 00.99
31 1 Comma Alpha (,) 2Ch
32 2 Width Temperature Numeric 00-99
34 1 Comma Alpha (,) 2Ch
35 2 Height Temperature Numeric 00.99
37 1 End of Text Control (ETX) 03h
38 1 Carriage Return Control (CR) 0Dh
39 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
21Values Command Alpha (V) 56h
3 1 Neg. Acknowledge Alpha (N) 4Eh
4 1 End of Text Control (ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
6 1 Line Feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Wgt. Unit Command Alpha (#) 23h
3 1 English or Metric Alpha (E/M) 45h or 4Dh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
