Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 78
Zero
This command should be issued periodically to force the CubiScan 25 to perform internal
compensations to adjust to changes in temperature and humidity. This command should only be
issued when the measuring field is free of objects! Never issue this command when an object is
present in the measuring field.
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Wgt. Unit Command Alpha (#) 23h
3 1 Acknowledge Alpha (A) 41h
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Wgt. Unit Command Alpha (#) 23h
31Neg. Acknowledge Alpha (N) 4Eh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
21Zero Command Alpha (Z) 5Ah
31End of Text Control(ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
51Line Feed Control(LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
21Zero Command Alpha (Z) 5Ah
3 1 Acknowledge Alpha (A) 41h
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
Pos Len Description Type Range ASCII
