Menu
Selection
Function
This item will not be highlighted if you have
not selected a 980.
Information
Provides information about the 980 that the
980 Manager is currently selected. This
information includes:
o 980 Name
o IP address of the 980
o Netmask
o Gateway IP address
o Hardware revisions of the 980 circuit
boards
o Firmware/Gateware version of the
release applied to the 980
o Serial number of the 980
o OS version
o Licensed options applied to the 980
Edit [the
Instrument Entry]
Enables you to edit certain information about
the 980 that you have selected. You can edit
the name and IP address.
Configure
[Instrument
Network]
Allows you to view and set the network
information such as the 980 IP address,
netmask and gateway IP address.
Upgrade GUI
Application
Upgrade GUI Application - Enables you to
apply an upgrade of the 980 built-in GUI. You
can download new GUI release from the
Quantum Data website on the downloads
page.
Upgrade Firmware/
Gateware
Upgrade Firmware/Gateware - Enables you
to apply an upgrade to the 980. You can
download new releases from the Quantum
Data website on the downloads page.
Upgrade System
Components
Upgrade System Components - Enables you
to apply an upgrade to the 980 HDMI Source
Compliance Test application or any other
optional application. You can download new
releases from the Quantum Data website on
the downloads page.
Set 980 License
Key
This enables you to activate a license for an
optional feature you have purchased. When
