Installation
Intelligent Electric Vehicle Chargepoints QUBEVSM-V01-R0 Installation and Operation Manual
Page 17 of 42 February 2023
16. Refit and secure the DIN rail and components.
17. Carefully place the charger body temporarily onto the mounting bracket so that cable
lengths can be determined.
18. Determine the most suitable cable routing and the cable length of all cables that will enter
the enclosure so that each cable can connect to the appropriate terminal(s).
x Cable routing may depend on the cable entry point(s) into the enclosure.
19. Terminate the supply cable in the appropriate manner and connect it to the charger as per
the schematic.
x 1-phase models will use the terminals L1, N and E (PE).
x 3-phase models will use the terminals L1, L2, L3, N and E (PE).
NOTE: The ethernet connection within the charger is solely for connection to an OCPP
back-office. It is not for use with the Smart Application.
20. If required, connect the ethernet cable and the CT cable to the charger.
x If the supplied rubber gromets will be used, the rubber may need to be carefully cut to
enable the ethernet cable to be fitted.
x The ethernet connector and the CT connector locations within the enclosure are
shown at Figure 2 on page 7.
x Details about CT installation are shown on page 19.
21. Make sure ALL accessible cable connections are secure and have not become loose or
damaged in transit or during installation.
22. Make sure ALL debris is removed from the enclosure and that no debris is present on any
of the components.
IMPORTANT NOTE:
It is the responsibility of the installing engineer to make sure that all accessible cable
terminations throughout this product are secure and tight and have not become loose,
strained, or disconnected during transit and/or installation.
NOTE: All electrical work must be performed in accordance with the current Electrical Wiring
Regulations.
CAUTION: Equipment Damage – Sensitive Equipment
If you will be performing insulation resistance tests on the power supply cables, it is advised
to be done BEFORE connecting the cable to the charger. The high voltages applied during
the test may damage sensitive components if tested after the cable is connected.
