Product Specification
QUBEVSM-V01-R0 Installation and Operation Manual Intelligent Electric Vehicle Chargepoints
February 2023 Page 6 of 42
Product Specification
Physical Specification
Enclosure Dimensions 330mm x 200mm x109mm (H x W x D)
Enclosure Materials PC/ABS Alloy
Mass
x 2.5kg 1-Phase, Single Socket
x 2.75kg 3-Phase, Single Socket
x 4.7kg 1-Phase, Tethered Cable
x 6.0kg 3-Phase, Tethered Cable
Operating Temperature -25°C to +50°C
Humidity 3%~95%
Altitude <2000m
Protection
x IP65 – Enclosure Ingress
x IP54 – Socket/Plug Ingress
x UL94-V0 Fire Rated
x IK08 Impact
Figure 1 Enclosure Dimensions
