Intelligent Electric Vehicle Chargepoints QUBEVSM-V01-R0 Installation and Operation Manual
Page 7 of 42 February 2023
Figure 2 Internal Arrangement (3-phase, socket model shown)
NOTE: Except for the number of incoming power terminals, the internal arrangements of all
models are very similar.
Rear Enclosure
Incoming
Power
Terminals
Anti-tamper
Switch
Socket
Terminals
LED Indicator
Cable
Ethernet Port for
OCCP
Communications
External CT
Connector
DIP Switches
Below PEN Module
PEN Module
Function
Button
