Operation
Intelligent Electric Vehicle Chargepoints QUBEVSM-V01-R0 Installation and Operation Manual
Page 33 of 42 February 2023
Charger Status Indications
The charger status indicator is located on the front of the enclosure.
Operational Indications
No Light No power to charger.
Blue, Green and
Red flashing
alternately
Product power-on self-check.
Blue Glowing Standby.
Blue Flashing Connection confirmation
Green Glowing Charging.
Green Flashing Charging complete. Turn off charging via App or OCPP.
Fault Indications
No Light
No power to
charger.
Red flashing
4 fast 1 slow
Over voltage fault
Red flashing
1 fast 2 slow
CP fault
Red flashing
6 fast 2 slow
Adhesion fault
Red flashing
2 fast 1 slow
Over current
Red flashing
7 fast 1 slow
Earth fault
Red flashing
3 fast 1 slow
Leakage
current fault
Red Glowing Over temperature
Red flashing
3 fast 2 slow
Under voltage
fault
