TMS STRING PINSPOTTER OWNER’S MANUAL
400-051-010-01 Rev. Date: 6/17 Page 5-55
610-051-016 – TMS Ladder Kit
610-051-016 – TMS Ladder Kit
Item
Part Number
Description
1
051-070-028
LADDER WELDMENT
2
088-200-884
LEFT-HAND LADDER WELDMENT FOOT
3
088-200-885
RIGHT-HAND LADDER WELDMENT FOOT
4
801-749-121
FBCS 1/4-20 X 0.75 GR8 BO
5
856-149-001
HFLN 1/4-20 BO STV
6
810-564-420
HHLB 3/8 X 2.00 ZN
7
947-367-141
FW 3/8 USS BO
8
730-069-640
ANCR SL 3/8 X 1.75 NS
