Page #48 background imageLoading...
Page #48 background image
GL300 @Tracker Air Interface Protocol
5 Bit 4
The GPRS network is not attached
6 Bit 5
The GSM network registered
7 Bit 6
The GSM network not registered
8 Bit 7
Network roaming
9 Bit 8
Network non roaming
10 Bit 9
SIM card is locked
11 Bit 10
GPS is opened
12 Bit 11
GPS is closed
13 Bit 12
The device is stationary
14 Bit 13
The device is moving
15 Bit 14
External charge inserted
16 Bit 15
No external charge.
17 Bit 16
The device is charging
18 Bit 17
The device is not charging
19 Bit 18
External battery inserted
20 Bit 19
No external battery
21 Bit 20
Digital input 1 is low
22 Bit 21
Digital input 1 is high
23 Bit 22
SIM card is inserted.
24 Bit 23
SIM card is not inserted
25 Bit 24
Reserved
26 Bit 25
Reserved
27 Bit 26
Inside the Geo 0
28 Bit 27
Outside the Geo 0
29 Bit 28
Inside the Geo 1
30 Bit 29
Outside the Geo 1
31 Bit 30
Inside the Geo 2
32 Bit 31
Outside the Geo 2
33 Bit 32
Inside the Geo 3
34 Bit 33
Outside the Geo 3
35 Bit 34
Inside the Geo 4
36 Bit 35
Outside the Geo 4
37 Bit 36
Inside the speed range
38 Bit 37
Outside the speed range
39 Bit 38
Messages need to be sent
40 Bit 39
No messages need to be sent
41 Bit 40
SOS event
<Debounce time>: The debounce time for input events before executing the specified stored
commands.
<Stocmd id mask>: The bitwise of the stored commands which will be executed after the
state of the group becomes TRUE (i.e. all cared input events happen.).
TRACGL300AN001 - 47 -
Queclink
Confidential
