Why is the Quin Q-drive Amplifier motor rotation not smooth?
If the motor rotation isn't smooth, check if the motor pole pairs parameter is incorrect or if the motor wiring on terminals U, V, W is not in the correct sequence.
Why does the Quin Q-drive motor turn in the wrong direction?
If the motor turns in the wrong direction, it means the command signal is wired incorrectly. Reverse connections to PP10.3 and P10.4 and change the setting of jumper J3.
What does Display 4 mean on a Quin Q-drive Amplifier?
If Display 4 is shown, the servo-amplifier is overloaded, possibly due to a cooling fan failure.
What does it mean if my Quin Amplifier shows Display 7?
If Display 7 appears, it indicates a brake fuse failure or that it is missing. This can occur in case of over-voltage or a missing supply.
What does Display 2 mean on Quin Amplifier?
If Display 2 is displayed, it indicates that the limit of continuous current has been reached because the Resolver Shift Angle parameter is incorrect.
What does Display 6 mean on Quin Amplifier?
If Display 6 appears, it signifies a resolver failure or resolver wiring failure.
What does Display 5 mean on Quin Q-drive?
If Display 5 is displayed, it indicates a resolver conversion circuit failure or that the Resolver Shift Angle parameter is incorrect.
What does Display C mean on Quin Q-drive?
If Display C is displayed, it indicates a motor connection failure.
What does Display d mean on Quin Q-drive?
If Display d is displayed, it indicates detection of a motor ground defect (option) with auto-transformer.
Illustrates the fixing centers and clearance required for mounting the Q-Drive unit.
Details connections for Encoder, Resolver, RS422/RS232, and discrete signals.
Explains the connections for three-phase supply, earth terminals, and motor output.
Describes the available power sources and requirements for the Q-Drive.
Emphasizes safety and system integrity through proper earthing procedures.
Instructions for connecting the motor, including cable specifications and best practices.
Guides on connecting the Q-Drive to a Quin motion controller for operation.
Guidelines for securely mounting the motor to prevent vibration and ensure stability.
Procedures for connecting the motor shaft to the load, addressing backlash.
Instructions on installing and navigating the QDRIVE.EXE configuration software.
Explains how to view real-time status and alarm information of the drive.
Steps for powering up the drive with the motor connected and initial optimization.
Methods for adjusting Proportional Gain and Integral Gain for optimal performance.
A guide to identifying and resolving common problems and error codes.
