56
Appendix 1.Remote controller operation
Serial Number Name Function
1
Multi-windowbutton SamefunctionasMulti-windowbuttoninthefrontpanel
2 Numeric button Code input/number input/channel switch
3 (Esc) Same function as (Esc) button in the front panel
4 Direction button Same function as direction button in the front panel
5 Record control Control the record
6 Record mode
Samefunctionas“Recordmode”
7 ADD Input the number of DVR to control it
8 FN Assistant function
Appendix 2.Mouse operation
*Take right hand as an example
The mouse in USB connection is supported.
Operation Function
Double left click
Doubleclickoneiteminthelelisttoplaybackthevideo
Double click the playback video to zoom in or out the screen
Double click the channel to make it full screen display
doubleclickagaintoresumethemulti-windowdisplay
Left click Choose the according function in the menu
Right click Pop desktop shortcut menu in preview state
Current shortcut menu in the menu
Press middle
button
Add or subtract number in the number setting
Switchtheitemsinthecombobox
Page up or down in the list
Move mouse Choose the widget or move the item in the widget
Drag mouse Set the motion detect area
Set the cover area
(6)(1) (5) (8)(7) (4) (3) (2)
