6
2 Initial check and cable connections
2.1 Initial check
WhenyourstreceiveyourDVR,pleasecheckthefollowing:
1. Please check whether there is any visible damage to the package
appearance. The protective materials used for the package of the DVR can
protect the DVR against most accidental damage during transportation.
2. Pleaseopentheboxandgetridofftheplasticprotectivematerials.Check
whether there is any visible damage to the DVR itself.
3. Pleaseopenthemachinecrustandcheckthedatawireinthefrontpanel,
power wire and the connection between the fan power and the main board.
Front and rear panel
l
Thekeyfunctionsonthefrontpanelandtheinterfacespecicationforthe
realpanelareinthespecication.
l Please check the product type described on the front panel whether is the
product type you ordered.
The label on the real panel is very important for after sales service. Please
protectitcarefully.Ifyouhavetocontactusforaftersalesservice,please
provide the product type and serial number from this label.
2.2 Hard disk installation
BeforeyourstusetheDVR,pleaseinstalltheharddiskasfollows:-
1). Undo the side screws 2). Lift off the cover
3).
Screw on the hard disk 4). Screw on the hard disk
