User’s Manual 67
A.3 Jumper Configurations
Figure A-5 shows the header locations used to configure the various BL2100 options via jumpers.
Figure A-5. Location of BL2100 Configurable Positions
JP3
JP1
Top Side
JP2
Bottom Side
R60
R59
R61
R56
R54
R57
R69
R71
R70
