User’s Manual 79
APPENDIX C. LCD/KEYPAD MODULE
An optional LCD/keypad is available for the BL2100. Appendix C
describes the LCD/keypad and provides the software APIs to
make full use of the LCD/keypad.
C.1 Specifications
Two optional LCD/keypad modules—with or without a panel-mounted NEMA 4 water-
resistant bezel—are available for use with the BL2100. They are shown in Figure C-1.
Figure C-1. LCD/Keypad Module Versions
Only the version without the bezel can mount directly on the BL2100; either version can
be installed at a remote location up to 60 cm (24") away. The version without a bezel is
also sold with the enclosure described in Appendix D. Contact your Rabbit sales represen-
tative or your authorized distributor for further assistance in purchasing an LCD/keypad
module.
Mounting hardware and a 12.5 cm (5") extension cable are also available for the LCD/
keypad module through your sales representative or authorized distributor.
