any IP address routed through this RipEX. I.e. RipEX is woken up not only with packets
which end in it, but also with packets which end in the connected device behind RipEX or
which are relayed over the Radio channel (when this RipEX is configured as the Repeater
for them).
When an unexpected reboot happens while in the ACTIVE state, the RipEX enters the
ACTIVE state again and the "Timeout from wake-up" is reset. When a reboot happens while
in the SAVE state, the RipEX enters the SAVE state immediately after the reboot.
When one of the configurable parameters is changed while the RipEX is in the ACTIVE state,
the "Timeout from wake-up" is reset.
Timeout from wake-up [s]
Default = 300 (min. 60, max. 64800)
RipEX stays ACTIVE for the set time from the moment of its wake-up. When this timeout
expires, the RipEX switches back to the SAVE state.
NOTE: It is possible to put RipEX into SAVE state anytime using the respective CLI
command.
Reset timeout on received packets
List box: On, Off
Default = Off
If "On", the "Timeout from wake-up" is reset whenever a packet is received or transmitted
over the Radio channel channel by the RipEX in the ACTIVE state. Consequently the
RipEX stays in the ACTIVE state as long as it communicates over the Radio channel
channel.
NOTE:
HW wake-up
With any fw version higher than or equal to 1.2.1.0 you can take a RipEX in Save state,
cycle the power and during the boot-up (approx. 48 sec.) the LED Status starts to flash
quickly in green for approx. 10 sec. When Reset button is pressed for approx. 1 sec.
during that period of quick blinking, the Power supply mode is set to Always On and the
unit can be accessed in the usual way (Ethernet or "X5" USB/ETH adapter)
Sleep Mode
Sleep Mode is controlled via the digital input on Power and Control connector. When the
respective pin (SI) is grounded, RipEX goes to sleep and consumes only 0,07 W. The time
needed for a complete wake-up from the Sleep mode is approx. 48 seconds (booting time).
Timeout from sleep request [s]
Default = 10
RipEX remains On for the set time from the moment when the sleep input pin has been
grounded. When SI pin on Power and Control connector is not-grounded for 1 sec. (or
more) during this Timeout, the timeout is reset and starts again.
NOTE: When Hot Standby is "On", Save and Sleep modes are not available.
RipEX Radio modem & Router – © RACOM s.r.o.108
Advanced Configuration
