Electrical
10 to 30 VDC, negative GNDPrimary power
5 W/13.8 V; 4.8 W/24 V; (Radio part < 2 W)Rx
Power consumptionRF power
Tx - Exponential - FSK
(4CPFSK, 2CPFSK)
13.8 V 24V
13.8 W 13.2 W0.1 W
15.2 W 14.4 W1 W
33.1 W 31.2 W5 W
41.4 W 38.4 W10 W
30.4 W 30 W
0.5 W
Tx - Linear - QAM
(16DEQAM, D8PSK,
π/4DQPSK)
1 W
2 W
0.1 WSleep mode
2 WSave mode
Interfaces
RJ4510/100 Base-T Auto MDI/MDIXEthernet
DB9FRS232
COM 1
300–115 200 bps
DB9FRS232/RS485 SW configurable
COM 2
300–115 200 bps
Host AUSB 1.1USB
TNC female50 ΩAntenna
LED panel
Power, ETH, COM1, COM2, Rx, Tx, Status7× tri-color status LEDs
Environmental
IP40, IP51*
* See Section 6.1.4, “IP51 mounting” for details.
IP Code (Ingress Protection)
> 900.000 hours (> 100 years)MTBF (Mean Time Between Failure)
−40 to +70 °C (−40 to +158 °F)Operating temperature
5 to 95 % non-condensingOperating humidity
−40 to +85 °C (−40 to +185 °F) / 5 to 95 % non-condensingStorage
Mechanical
Rugged die-cast aluminiumCasing
50 H × 150 W × 118 mm D (1.97× 5.9 × 4.65 in)Dimensions
1.1 kg (2.4 lbs)Weight
DIN rail, L-bracket, Flat-bracket, 19" Rack shelfMounting
SW
Bridge / RouterOperating modes
Modbus, IEC101, DNP3, PR2000, UNI, Comli, DF1, RP570,
Profibus, …
User protocols on COM
