95
174
184
Flat-bracket
134
150
118
58
50
70
Fig. 4.24: RipEX with Flat-bracket
95
174
184
8
70
75,4
2×o4,5 4×M3
/
101
Fig. 4.25: Flat-bracket dimensions
7. 19" rack shelf – single
• 1,6U (70 mm) high
• Ready for assembly with one RipEX
• Weight 2.5 kg (without power supply and RipEX)
• Can be assembled with power supply
○ 100 – 256 V AC / 24 V DC
○ 230 V AC / 24 V DC
○ 48 V DC / 24 V DC
○ MS2000/12 + back up battery 7.2 Ah
75© RACOM s.r.o. – RipEX Radio modem & Router
