• Outside dimension: 455 × 365 × 185 mm
• Weight approx. 4 kg (excluding the RipEX and M!DGE units)
5. L-bracket
Fig. 4.21: L-bracket
Installation L bracket for vertical mounting. For
details on use see chapter Mounting and
chapter Dimensions.
133
124
60
122
L -bracket
32
100
Fig. 4.22: RipEX with L-bracket
6. Flat-bracket
Fig. 4.23: Flat bracket
Installation bracket for flat mounting. For details
on use see chapter Mounting.
RipEX Radio modem & Router – © RACOM s.r.o.74
