Warning: Channels 8-14 are fixed at narrowband 12.5 KHz, channel
bandwidth change is prohibited.
6 RX CTCSS OFF;67-254.1
Mutes the speaker of the transceiver in the absence of a specific
and continuous sub-audible signal. If the station you are listening
to does not transmit this specific and continuous signal, you will
not hear anything.
7 RX DCS OFF;023N-754I
Mutes the speaker of the transceiver in the absence of a specific
low-level digital signal. If the station you are listening to does not
transmit this specific signal, you will not hear anything.
8 TX CTCSS OFF;67-254
Transmits a specific and continuous sub audible signal to unlock
the squelch of a distant receiver (usually a repeater).
9 TX DCS OFF;023N-754I
Transmits a specific low-level digital signal to unlock the squelch
of a distant receiver (usually a repeater).
10 Encryption
OFF Disable encrypted mode, your conversations are not private.
ON
Activating encryption mode ensures the privacy of your
conversations.
To use the Encryption function, the other part of the radio must
also have Encryption activated and must be tuned on the same
DCS code.
11 Signaling 1-20
Selects 1 of 15 DTMF codes. The DTMF codes are programmed
with software and are up to 5 digits each.
12 CH-MDF
NAME
MR/Channel mode is displayed in NAME format. Note: NAME
allows CPS program or edit in the channel name（Munu 1）.
FREQ MR/Channel mode is displayed in frequency format.
CH MR/Channel mode is displayed in CH format.
13 SP-Mute
QT
when radios is set in this mode, the monitor feature is activated
only when the radio receives the correct CTCSS/DCS.
QT*DTMF
• QT*DTMF: the monitor is activated when the radio receives the
correct CTCSS/DCS or the correct DTMF code.
14 SCAN ADD
OFF Forbid the current channel to join the scan group.
ON Add the current channel to the scan group.
15 Busy Lockout OFF The [PTT] button on the channel is always allowed.
