2. Dual-engine Models: Being dual-engine category, tracked vehicle has two motors and each track is
driven by each motor.
3. Mix Control: The throttle (a function) on R/C monitors two motors （ two execute unites) move
forward/backward simultaneously. That is, ONE TO TWO mix control. On the other hand, the turning of
steering wheel makes one motor forward while the other backward at the same time to achieve direction
turning. Same as ONE TO TWO mix control.
4. Dual Mix Control： As controlling dual-engine vehicles drive forward/backward and turn left/right, two mix
controls at the same time are needed. RadioLink RC4GS V3 has two programmable mix controls.
Reverse Setup before Mix Control Setup
Before setting the mix controls, please check if the reverses working correctly by testing its wheel and
throttle. Take steering wheel-- left track (Ch1 on receiver) and throttle--right track(Ch2 one receiver) as
example.
1. Throttle Reverse：NOR-REV
Hold RC4GS V3 as the below pic. Normally, pull the throttle, the right track should be moving forward while
push the throttle and the right track should be backward.
If pulling the throttle and the left track moves backward; Or pushing the throttle and the left track moves
forward, meaning the initial throttle is reversed and needs to be set. Please refer to the “button operation”and
get into below interface to complete the setup.
Pull the throttle，right track moves forward，left track remains still
