CH5: Channel5(SWD)
RANGE:
Servo: -100~+100
Throttle: -100~+100
CH3: -100~+100
CH4: -100~+100
CH5: -100~+100
Initial value: 0
(1) Enter the menu, use “Dec (-)” and “Inc (+)” to select options to set.
(2) Press the button key “Enter” to enter menu.
(3) Use “Dec (-)” and “Inc (+)” to select SERVO, then press “Enter”. Now the initial value
of SERVO will start flashing, use handle to change the value.
(4) Press the button key “Enter”, the value stops flashing, now the value of SERVO is set.
(5) THROTTLE is to set by the trigger.
CH3 is to set by VR controller.
CH4 is to set by the button switch.
CH5 is to set by the button switch.
(6) Press “Exit” two times to back to initial screen.
2.22 Subsidiary ID “ID SEED”
ID SEED function means designating a subsidiary ID among multiple binding receivers to realize the control.
There are totally 10 independent subsidiary IDs can be stored. The four numbers displayed at the bottom of
the screen are the independent ID codes of this transmitter.
For example, RC4GS V3 has completed the binding with 10 different boats and the setup of respective
parameters. Turn on the ID SEED function, select ID.1 boat and drive it to the central of water but it stops
working unexpectedly. Then we can change to the ID.2 boat (or any other subsidiary ID boat preferred) and
control it independently to rescue ID. 1 boat instead of controlling both boats at the same time, which makes
the rescue more difficult. Unlike traditional binding mode, independent ID can easily realize rescuing stalled
boat in the water caused by various reasons.
Press EXIT and ENTER simultaneously to enter MENU=>press Inc(+)/DEC （ - ） to highlight “22. ID
SEED=>Press ENTER => Change the MODE from OFF to ON=> set the subsidiary ID number=> complete
biding and parameters setting.
Once finished , the corresponding ID number will be displayed on the RC4GS V3 main interface .
