RadioLink RC4GS V3 User Manual

RadioLink Electronic Limited
www.radiolink.com
6
 Size: 174.8*116.4*224.2mm(6.88*4.58*8.83")
 Weight: 319g(11.28oz)
 Channel: 5 channels
 Model Memory: 30 ID seed: 10
 Antenna Length: 106mm(4.17")
 Control Range: 400 meters
 Operating Current: 80-120mA
 Operating Voltage: 4.8-16.8V, (6pcs of AA batteries or a 2S-4S LiPo battery)
 RF Power: <20dbm
 Frequency: 2.4Ghz ISM Band（2400MHz--2483.5MHz）
 Modulation Mode: GFSK
 LCD Screen: 128*64 Resolution, LCD Backlight
 Channel resolution: 4096 with regular jitter of 0.5us
 Spread Spectrum: FHSS 67 Channels Pseudo Random Frequency Sequence Hopping
 Low Voltage Alarm: Yes. When less than 7.2V or customized on 2-4S battery. (Customizable for each
model)
 Adaptable Models: Car (Incl. Crawlers/Tanks/Caterpillars etc.)/Boat/Robot
 Compatible Receiver: R6FG(Standard), R8FG, R7FG, R6F, R8EF, R8F, R4FGM, R4F
 Battery Tray Dimension: 89*59*25mm (3.5*2.32*0.98")
1.2 Receiver R6FG(Standard Pack)
Receiver packed with RC4GS V3 is R6FG, 2.4GHz 6 channels, gyro integrated and high voltage servo
supported.
1.2.1 R6FG Specification
 Size: 35*20*13mm (1.38*0.79*0.51")
 Weight: 6g (0.21 oz)
 Channel: 6 channels
 Antenna Length: 205mm(8.07")
 Operating Current: 30mA
 Operating Voltage: 3-12V

RadioLink RC4GS V3 Specifications

General

Channels	4
Frequency	2.4GHz
Model Memory	10 models
Telemetry	Yes
Modulation Mode	FHSS
Spreading Spectrum	DSSS
Screen	128*64 LCD
Low Voltage Alert	Yes
Simulator	Yes
Weight	320g
RF Power	<20dBm
Band	2.4GHz
Display	LCD
Fail-Safe	Yes
Power Supply	6x AA batteries or 2S LiPo
Adjacent Channel Rejection	>38dB
Transmitter Power	<20dBm
Operating Voltage	4.8~8.4V
Model Type	Car/Boat
