Chapter 5 Diagnostics and Troubleshooting WinLink 1000 Installation and Operation Manual
Table 5-1. WinLink 1000 Alarms and Information Messages
Message Description
Radio Link – Sync Radio link is synchronized
Radio Link – Out Of Sync Radio link lost synchronization
Link Has Been Reset ODU was reset due to internal problem
TDM Interface – Normal TDM interface is operating properly
TDM Interface – LOS Loss of Synchronization is reported by TDM interface
TDM Interface – LOS
Loss of Signal is reported by TDM interface
TDM Interface – AIS
Alarm Indication Signal is reported by TDM interface
TDM Interface – Loopback
A loopback is active on TDM interface
Link Resetting Wireless link reset from the management station. This
alarm is caused by automatic reset after link
configuration.
Local ODU Resetting The local ODU reset from the management station.
Monitor was stopped since no
connection to the link
No ODU-to-IDU traffic was detected during the last 20
minutes.
5.2 Collecting and Saving Statistics
WinLink 1000 constantly monitors traffic over the radio link and
collects the following statistics data:
Site 1/Site 2 received traffic rate (in Kbps)
Site 1/Site 2 received frames rate (in Fps)
Radio signal strength (in dBm)
Error (Blocks).
The statistics (monitor) log and event log can be saved as TXT files.
New alarms are automatically added to the text file, as they enter the
event log.
Î
To save event log or monitor log:
1. From the Tools menu, choose Preferences.
The Preferences dialog box appears (see
Figure 5-1
).
2. From the Preferences dialog box, select the file to save.
5-2 Collecting and Saving Statistics
