Figure 6-14 Wiring of 1000 Mbit/s crossover cable
6.1.7 Clock cable
Introduction
The ISCOM RAX711 adopts the RJ45 clock interface for inputting and outputting 2 Mbit/s or
MHz clock signals.
Appearance
Figure 6-15 shows the clock cable for the 2 Mbit/s or MHz interface.
Figure 6-15 Clock cable for 2 Mbit/s or MHz interface
Technical specifications
Table 6-13 list technical specifications of the RJ45/RJ45 clock cable for the ISCOM RAX711.
Table 6-13 Technical specifications of RJ45/RJ45 clock cable
Item
Description
Connector
RJ45 crystal head
