Table 6-17 Parameters of 1000BASE-X SFP optical module
Model
Wavelength
(nm) (laser
type)
Rx
type
Tx
optical
power
(dBm)
Minimum
overload
point (dBm)
Extinction
ratio (dB)
Rx
sensitivity
(dBm)
Transmission
distance (km)
USFP-
Gb/M-D-R
850 (VCSEL)
PIN
-10 to -
3
-3
9
-15
0.55
USFP-
Gb/S1-D-
R
1310 (FP)
PIN
-10 to -
3
-3
9
-21
15
USFP-
Gb/S2-D-
R
1550 (DFB)
PIN
-3 to 2
-3
9
-21
40
USFP-
Gb/S3-D-
R
1550 (DFB)
APD
-3 to 2
-9
9
-30
80
USFP-
Gb/LH1-
D-R
1310 (DFB)
PIN
-4 to 0
-3
9
-21
40
USFP-
Gb/ZX-D-
R
1550 (DFB)
PIN
-2 to 3
-3
9
-22
80
USFP-
Gb/EX-D-
R
1550 (DFB)
APD
0–5
-9
9
-30
120
USFP-
Gb/SS13-
D-R
TX1310/RX1
550 (FP/DFB)
PIN
-10 to -
3
-3
9
-21
15
USFP-
Gb/SS15-
D-R
TX1550/RX1
310 (FP/DFB)
PIN
-10 to -
3
-3
9
-21
15
USFP-
Gb/SS13-4
TX1310/RX1
490 (DFB)
PIN
-10 to -
3
-3
9
-21
15
USFP-
Gb/SS14-3
TX1490/RX1
310 (DFB)
PIN
-10 to -
3
-3
9
-21
15
USFP-
Gb/SS24-
D-R
TX1490/RX1
550 (DFB)
PIN
-3 to 2
-3
9
-21
40
USFP-
Gb/SS25-
D-R
TX1550/RX1
490 (DFB)
PIN
-3 to 2
-3
9
-21
40
USFP-
Gb/SS34-
D-R
TX1490/RX1
550 (DFB)
PIN
-3 to 2
-3
9
-29
100
