Raisecom
ISCOM2600G (A) Series Product Description
2 Networking applications
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
14
Figure 2-1 Enterprise park network access networking
2.2 Residential area broadband access
As an access switch, the ISCOM2600G series switch can work as a core switch for a small
network. As shown in Figure 2-2, the ISCOM2600G series switch is connected to the L3
aggregation switch through the 10GE interface and downstream to the 1000 Mbit/s switch
through the GE interface.
