Page #56 background imageLoading...
Page #56 background image
Raisecom
ISCOM2600G (A) Series Product Description
3 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
44
LED
Status
Description
SNMP
Green
SNMP interface working status LED
Green: the SNMP interface is properly connected.
Blinking green: the SNMP interface is receiving or
sending data.
Off: the SNMP interface is disconnected or improperly
connected.
SYS
Green
System working LED
Green: the system is working improperly.
Blinking green (every 1s): the system has loaded the
configuration file or the device is configured.
Off: the system is working improperly.
POE
Green
POE mode switching LED
Green: LEDs 124 correspond to the PoE status of the
corresponding interfaces.
Off: LEDs 124 corresponds to the LNK/ACT status of
the corresponding interfaces.
3.4.8 ISCOM2648G-4GE
Table 3-21 lists LEDs on the ISCOM2648G-4GE.
Table 3-21 LEDs on ISCOM2648G-4GE
LED
Status
Description
Port1Port48
LNK/ACT
LED
Green
Ethernet interface working status LED
Green: the interface is properly connected.
Blinking green: the interface is receiving or sending data.
Off: the interface is disconnected or improperly connected.
Port1
Port48
SPEED LED
Green
Ethernet interface working rate LED
Green: the interface works at 1000 Mbit/s.
Off: the interface works at 100 Mbit/s or stops working.
LNK/ACT
Port49
Port52
Green
Combo interface working status LED
Green: the interface is properly connected.
Blinking green: the interface is receiving or sending data.
Off: the interface is disconnected or improperly connected.
SPEED
Port49
Port52
Green
Combo interface working rate LED
Green: the interface works at 10 Gbit/s.
Off: the interface works at 1000 Mbit/s or stops working.
PWR
Green
Power working status LED
Green: the power supply is normal.
Off: the power supply is off, the power module fails, or the
power supply is configured as a single power supply and not
installed.
