Raisecom
ISCOM2600G (A) Series Product Description
3 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
24
1
Service downlink interfaces (148) and LEDs
2
Service uplink SFP optical interfaces (4952)
3
Uplink interfaces, SNMP interface, SYS, and
PWR1/PWR2
4
SNMP interface and Console interface
3.1.2 Rear panels
ISCOM2608G-2GE-AC/DC
Figure 3-17 shows the rear panel of the ISCOM2608G-2GE-AC/DC.
Figure 3-17 Rear panel of ISCOM2608G-2GE-AC/DC
ISCOM2608G-2GE-PWR-AC/DC
Figure 3-18 shows the rear panel of the ISCOM2608G-2GE-PWR-AC/DC.
Figure 3-18 Rear panel of ISCOM2608G-2GE-PWR-AC/DC
ISCOM2624G-4C-PWR-AC
Figure 3-19 shows the rear panel of the ISCOM2624G-4C-PWR-AC.
Figure 3-19 Rear panel of ISCOM2624G-4C-PWR-AC
1
Ground terminal
2
Power switch
3
Power interface
