Figure 3-14 Front panel of the ISCOM2648G-4C-AC/DC/S
1
Service downlink interfaces (1–48) and LEDs
2
Service uplink SFP optical interfaces (49–52)
3
Uplink interfaces, SNMP interface, SYS, and
PWR1/PWR2
4
SNMP interface and Console interface
ISCOM2648G-4C-AC/DC/D
Figure 3-15 shows the front panel of the ISCOM2648G-4C-AC/DC/D.
Figure 3-15 Front panel of the ISCOM2648G-4C-AC/DC/D
1
Service downlink interfaces (1–48) and LEDs
2
Service uplink SFP optical interfaces (49–52)
3
Uplink interfaces, SNMP interface, SYS, and
PWR1/PWR2
4
SNMP interface and Console interface
ISCOM2648G-4C-AC_DC
Figure 3-16 shows the front panel of the ISCOM2648G-4C-AC_DC.
Figure 3-16 Front panel of the ISCOM2648G-4C-AC_DC
