Raisecom ISCOM2624G-4C User Manual

Raisecom
ISCOM2600G (A) Series Product Description
6 Appendix
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
68
Connector (RJ45)
EIA/TIA 568A
EIA/TIA 568B
PIN 5
White/Blue
White/Blue
PIN 6
Orange
Green
PIN 7
White/Brown
White/Brown
PIN 8
Brown
Brown
Both two RJ45 connectors of the 10/100/1000 Mbit/s straight-through cable follow
EIA/TIA568B standard wiring.
Figure 6-3 shows wiring of the 10/100/1000 Mbit/s straight-through cable.
Figure 6-3 Wiring of 10/100/1000 Mbit/s straight-through cable
Figure 6-4 shows wiring of the 100 Mbit/s crossover cable.

Raisecom ISCOM2624G-4C Specifications

General

Brand	Raisecom
Model	ISCOM2624G-4C
Category	Switch
Language	English
