Page #46 background imageLoading...
Page #46 background image
Raisecom
ISCOM2600G (A) Series Product Description
3 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
34
1000 Mbit/s SFP optical interface
Table 3-3 lists parameters of the 1000 Mbit/s SFP optical interface.
Table 3-3 Parameters of 1000 Mbit/s SFP optical interface
Parameter
Description
Connector type
LC/PC
Optical interface properties
Depend on the selected SFP optical module.
Coding type
8B/10B
Working mode
Full duplex
Standard
IEEE 802.3-compliant
100 Mbit/s SFP optical interface
Table 3-4 lists parameters of the 100 Mbit/s SFP optical interface.
Table 3-4 Parameters of 100 Mbit/s SFP optical interface
Parameter
Description
Connector type
LC/PC
Optical interface properties
Depend on the selected SFP optical module.
Coding type
4B/5B
Working mode
Full duplex
Standard
IEEE 802.3-compliant
1000 Mbit/s Ethernet electrical interface
Table 3-5 lists parameters of the 10/100/1000 Mbit/s Ethernet electrical interface.
Table 3-5 Parameters of 10/100/1000 Mbit/s Ethernet electrical interface
Parameter
Description
Connector type
RJ45
Working mode
10/100/1000 Mbit/s auto-negotiation
Full/Half duplex auto-negotiation
Cable specifications
When the interface is working at 10/100 Mbit/s, we
recommend using the Cat 5 UTP cable.
When the interface is working at 1000 Mbit/s, we
recommend using the Cat 5e UTP or STP cable.
Standard
IEEE 802.3-compliant
