3.4.4 ISCOM2624G-4GE-PWR
Table 3-16 lists LEDs on the ISCOM2624G-4GE-PWR.
Table 3-17 LEDs on ISCOM2624G-4GE-PWR
LED
Status
Description
LNK/ACT
1–24
Green
Ethernet interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
–
Port 1–Port 8
PoE
Green
PoE working status LED

Yellow: the interface is supplying power to the remote
device.

Off: the interface is not supplying power to the remote
device.
LNK/ACT
25–28
Green
Combo interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
PWR
Green
Power working status LED

Green: the power supply is normal.

Off: the power supply is off or the power module is
improperly installed.
SNMP
Green
SNMP interface working status LED

Green: the SNMP interface is properly connected.

Blinking green: the SNMP interface is receiving or sending
data.

Off: the SNMP interface is disconnected or improperly
connected.
SYS
Green
System working LED

Green: the system is working improperly.

Blinking green (every 1s): the system has loaded the
configuration file or the device is configured.

Off: the system is working improperly.
PoE
Green
PoE mode switching LED

Green: LED 1–24 indicates the PoE status of the
corresponding interfaces.

Off: LED 1–24 indicates the LNK/ACT status of the
corresponding interfaces.
3.4.5 ISCOM2624G-4GE-RPS
Table 3-18 lists LEDs on the ISCOM2624G-4GE-RPS.
