ISCOM2600G (A) Series Product Description
3 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
45
LED
Status
Description
SNMP
Green
SNMP interface working status LED

Green: the SNMP interface is properly connected.

Blinking green: the SNMP interface is receiving or sending
data.

Off: the SNMP interface is disconnected or improperly
connected.
SYS
Green
System working LED

Green: the system is working improperly.

Blinking green (every 1s): the system has loaded the
configuration file or the device is configured.

Off: the system is working improperly.
3.4.9 ISCOM2648G-4GE-RPS
Table 3-22 lists LEDs on the ISCOM2648G-4GE-RPS.
Table 3-22 LEDs on the ISCOM2648G-4GE-RPS
LED
Status
Description
Port1–Port48
LNK/ACT LED
Green
Ethernet interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
–
Port1–Port48
SPEED LED
Green
Ethernet interface working rate LED

Green: the interface works at 1000 Mbit/s.

Off: the interface works at 100 Mbit/s or stops working.
LNK/ACT
Port49–Port52
Green
Combo interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
SPEED
Port49–Port52
Green
Combo interface working rate LED

Green: the interface works at 10 Gbit/s.

Off: the interface works at 1000 Mbit/s or stops working.
PWR
Green
Power working status LED

Green: the power supply is normal.

Off: the power module is not powered on or fails, or the
power module is configured as single power and not
installed.
SNMP
Green
SNMP interface working status LED

Green: the SNMP interface is properly connected.

Blinking green: the SNMP interface is receiving or
sending data.

Off: the SNMP interface is disconnected or improperly
connected.
