ISCOM2600G (A) Series Product Description
3 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
46
LED
Status
Description
SYS
Green
System working LED

Green: the system is working improperly.

Blinking green (every 1s): the system has loaded the
configuration file or the device is configured.

Off: the system is working improperly.
RPS
Green
RPS power LED

Green: the RPS is supplying power.

Off: the RPS is not supplying power.
3.4.10 ISCOM2648G-4C
Table 3-23 lists LEDs on the ISCOM2648G-4C.
Table 3-23 LEDs on ISCOM2648G-4C
LED
Status
Description
–
Port1–Port48
Green
Ethernet interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
LNK/ACT
Port49–
Port52
Green
10 Gbit/s SFP+ interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
PWR1/2
Green
Power working status LED

Green: the power supply is normal.

Off: the power supply is off, the power module fails, or the
power supply is configured as a single power supply and not
installed.
SNMP
Green
SNMP interface working status LED

Green: the SNMP interface is properly connected.

Blinking green: the SNMP interface is receiving or sending
data.

Off: the SNMP interface is disconnected or improperly
connected.
SYS
Green
System working LED

Green: the system is working improperly.

Blinking green (every 1s): the system has loaded the
configuration file or the device is configured.

Off: the system is working improperly.
