3 Installing chassis
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
16
The device may be damaged after leaving the factory during transport or due to other reasons.
Therefore, we recommend conducting power-on self-test to avoid installing a damaged one.
Check the device according to the following steps:
Step 1 Take the chassis out of the packing box. Put it on a stable workbench or floor in the
equipment room.
Step 2 Connect the ground cable according to section 3.3.4 Connecting ground cable.
Step 3 Install components according to chapter 4 Installing components.
Step 4 Install the power cable according to chapter 5 Connecting cables.
Step 5 Power on the device after components, ground cable, and power cable are correctly installed.
Step 6 Check the status of card LEDs.
If the LEDs are normal, install the device to the specified location according to the working
process flow.
For descriptions about LEDs, see ISCOM6820-GP (A) Hardware Description.
3.3 Installing chassis
3.3.1 Introduction
The ISCOM6820-GP device can be installed in the following scenarios:

ETSI 600-mm cabinet

19-inch 450-mm cabinet

19-inch 600-mm cabinet

Open rack

Workbench
When installing a chassis in a 600-mm cabinet, you need to purchase brackets
customized for the 600-mm cabinet
3.3.2 Installing chassis in cabinet
Wear a properly-grounded ESD wrist strap when installing the chassis and
components to prevent damage caused by static electricity.
If you wish to install the ISCOM6820-GP device in cabinet, refer to section 2.2 Checking
installation conditions to choose a cabinet which meets the following requirements:

The cabinet is strong enough to support the weight of the ISCOM6820-GP device and its
components.
