Raisecom
ISCOM6820-GP (A) Installation Guide
4 Installing components
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
26
Figure 4-6 Pulling the ejector levers outward
Step 5 Pull the card out of the slot slightly, as shown in Figure 4-7.
Figure 4-7 Pulling components outward
Step 6 Put the cards into an electrostatic box or electrostatic bag.
Pull up the connection cable or pigtail before inserting/removing cards. Insert blank
panels to slots which are unoccupied.
